Machine features
This radiator fin machine manufacturer produces radiator louver wave-type fins, a Special automatic processing machine with roll forming. A motor and a cylinder work together to drive the machine and facilitate automation in the production process. It has two working modes: automatic control and adjustment operation.
Automatic production mode of the machine, which realizes the automatic working cycle of automatic feeding, spray, rolling wave, and window opening, wave separation, wave receiving, wave peak counting, output accumulation, and cutting;
By adjusting the production mode, each working link can be started separately, and the spindle inching button is set to facilitate the debugging of the machine tool. The machine’s motor features variable frequency speed regulation, providing a wide range of speed control.
The cut-off wave number is controlled by the electronic counting of the servo worm system, which has accurate counting and strong anti-interference ability.
The feeding system has a supporting device that can rotate flexibly. It is also equipped with alarm protection systems, such as belt breaking and winding, which can automatically stop in the event of a sudden failure.
The radiator fin machine manufacturer manufactures its fin roller separately. Replacing the roller mold enables the production of different types of aluminum and copper fins.
This machine can produce radiator fins for cars, condenser fins for vehicles, condenser fins for household air conditioners, Intercoolers, and industrial heat exchanger fins. It is widely uses in shipbuilding, industry, automobile, motorcycle, and other fields.
Fin machine technical data
- Overall dimension: 4650 * 700 * 1750mm
- Foil material: aluminum & copper
- Foil thickness: 0.05-0.15mm
- Motor power: 2.2 KW
- Maximum production speed: 0-120 m/min
- Pressure: 0.6 Mpa
- Cutting speed: 60 times/min
- Power supply: 380V/50Hz
- Packing: wooden case
- name: aluminum fin machine
Machine Details
| ITEM | DATA |
| Touch screen size | 7 inches |
| Servo motor | 0.75kw |
| Cylinder brand | Hyde |
| Touch screen brand | Changhong |
| Motor brand | Delta |
| Lubricating oil | Volatile oil |
Radiator fin machine manufacturer video
