Bending machine of metal plate

Machine Overview

This bending machine is fully automatic metal plate bending equipment. It has a servo motor-driven clamping tool to control the movement and positioning of the metal plate.

The bending tool can achieve downward and upward bending actions. The machine can bend and form complex sheet metal parts through preset control programs.

This bending machine has no special requirements for the material of metal plates. Whether your plate material is galvanized sheet, aluminum, copper, stainless steel, or titanium alloy, it can easily bend to form the shape you need

Advantages of this bending machine

• Servo electric drive

Servo motor-driven clamping, precise control of the rapid movement of the metal plate. This servo motor is available on both the X and Y axes and can achieve 360 ° turning.

• Operational safety

Workers only need to place the metal plate on the work platform, and the clamping tool will automatically feed and bend it. Workers do not need to touch the bending area, and the operation is very safe.

• Centralized control station

This bending machine can be programmed and controlled, and engineers can preset bending steps at the control station. Even complex parts can be intelligently produced,

• No need for molds

Some tools on the bending machine can handle complex shapes, so workers do not need to frequently replace tools during production.

• Advantages of electronic control components

Our machine control components are all from internationally renowned brands such as Mitsubishi and Siemens. These high-quality parts ensure the smooth operation and service life of the plate bending machine.

Bending Machine Technical Parameters

Operation steps of bending machine

1, Preparation

Check the workbench and clean any unrelated items,

ensure that the positioning device is intact and that the bending tool is installation is very firm

2, Run the machine

Check that the power supply and start the bending machine, verify that the bending program meets the current production requirements

3, Production

Place the cut metal plate on the workbench, align it with the position, and press the start button. The machine will automatically complete the bending work.

4, Place the parts

Place the bent parts in the designated position, Workers need to repeat the previous step to achieve continuous production.

Security measures

1, The bending area of the machine is equipped with an infrared sensing device. When an object comes into contact with the machine, it will immediately stop to prevent worker injury

2, The workbench has tools to prevent placement errors, prevent workers from making mistakes during operation time, and avoid unnecessary losses

3, We can install a simple wall for the bending machine to isolate unnecessary interference and focus on safety production.

Bending machine working video

Conclusion

In modern industrial manufacturing, with the continuous upgrading of automation, this automatic bending equipment plays a vital role in the field of sheet metal production. It provides great convenience for large-scale part production. No matter how complex the structure of your sheet metal parts is, this machine can have a good solution.

If you are looking for this metal bending machine, please let us know, and our expertise can solve all your concern.
