Ekipman özellikleri
The Nitrogen making machine is a modern industrial equipment with an integrated design. It is control by Mitsubishi PLC, and both the inlet and outlet valves are automatically control by pneumatic valves. The touch screen can not only monitor nitrogen flow and purity, but also set automatic motion time and timed start and stop functions.
This nitrogen production machine adopts pressure swing adsorption technology, where high-quality molecular sieves absorb oxygen. Nitrogen smoothly enters the next adsorption tower through small channels, where it is purified to the required purity and stored in a nitrogen tank.
The Nitrogen Manufacturing Machine consists of an air compressor, an air storage tank, an oil filter, a refrigerated air dryer, a water filter, a combined suction dryer, an activated carbon filter, a nitrogen production machine, a nitrogen storage tank, and other components.
This nitrogen equipment is a fully automatic production line, with technical parameters such as nitrogen purity, nitrogen flow, nitrogen dew point, etc. We manufacture and customize it according to customer requirements.
Characteristics of Nitrogen making machine
en son teknoloji
The machine adopts a dual tower structure design, pressure swing adsorption technology, and a regeneration system. If the nitrogen purity is not up to standard, it can be returned to the adsorption tower for further purification of nitrogen.
Nitrogen purity can be customized
We accept customization of this nitrogen production line, with a range of nitrogen purity of 99% – 99.999% and nitrogen flow rate of 10 m ³ -1000 m ³ per hour.
Very simple usage process
The equipment adopts an integrated design, and workers only need one click to start it. There is no need for any manual participation in the nitrogen production process, and it only takes about 20 minutes from starting the equipment to producing qualified nitrogen.
Değişken frekans teknolojisi
The air compressor adopts the latest frequency conversion technology, which can significantly reduce the cost of electricity usage. Moreover, the noise generated by the operation of the air compressor is also much lower.
Düşük bakım maliyeti
The new air compressor requires maintenance after 200 hours of use, and we have prepared the necessary parts for maintenance. The first maintenance of the machine costs you zero, and the subsequent maintenance time is every 5000 hours.
Teknik parametre
- Adı: Azot yapma makinesi
- Azot üretimi: 300Nm3/h
- Basınçlı hava tüketimi: 45m3/dak
- Hava giriş basıncı: 0.65MPa
- Azot saflığı: %99.999
- Ortak nitrojenin çıkış basıncı: 04-0.6Mpa
- Ortak nitrojenin çiğlenme noktası: -40 OC
- Güç kaynağı: 220V, 50Hz
- Güç: 0.03 kW
- Dış boyutlar: 2200*1850*3350mm
- Çalışma prensibi: PSA PSA fiziksel azot üretim hattı
Outline design of nitrogen making machine
The appearance color of this nitrogen generator adopts a baking paint process, with a default color of light blue. All connecting pipes, bases, and two adsorption towers are of the same color.
The valve comes from a famous Chinese brand, and their opening and closing are automatically control by PLC. The connecting pipes of the valves are made of SS304 material, arranged scientifically, and have a very beautiful .
The base and adsorption tower are design as an integrated unit, and the frame has reserved holes for forklifts, making forklift handling very convenient.
There are reserved lifting holes on the adsorption tower. If your factory has aerial vehicles, you can use ropes to lift this equipment.
During normal operation, this nitrogen generator only needs to be connected to a 220V power supply, which is very energy-efficient.
Azot yapma makinesi uygulaması
| Kimya endüstrisi | Gıda fabrikası |
| Sanayi üretimi | cam üretimi |
| İlaç Fabrikası | Elektronik fabrika |
| Kömür madeni üretimi | sert alaşım |
| Petrol arıtma | Toz metalurjisi |
| ısıl işlem tesisi | Lehimleme endüstrisi |
Nitrogen making machine china factory video
Neden Azot yapma makinemizi seçmelisiniz?
Our technical team has extensive work experience, with an average working age of over 15 years. No matter which industrial field you come from, we can provide the best solution for your Azot üreteci.
A very competitive price, because every part is manufactured in the factory, so our nitrogen generator has an absolute price advantage.
Visual human-computer interaction, our air compressor and nitrogen generator both have a 7-inch dokunmatik ekran with Chinese and English displays, which ensures smooth operation of the equipment.
We provide long-term supply of parts required for equipment maintenance. Our parts are provided at factory prices and have sufficient inventory. Whenever you need parts, we can deliver them for maintenance at any time.
We provide meticulous delivery services and nitrogen generators for our global customers. No matter which country you come from, we can deliver the machines to your factory.
Soru ve Cevap
Normally, the dew point of nitrogen is -60. If you need a higher dew point, we can meet your requirements.
This machine adopts pressure swing adsorption technology, which does not require the addition of ammonia to improve the purity of nitrogen gas.
Yes, we also have this machine. We accept nitrogen machines of any specification.
This machine will be test in China and then disassembled for transportation. We provide installation services, but this machine is very simple. It only needs to be connected to the power supply and valves to operate normally in China.
